Description
Conmed Excallibur Plus Features
The Conmed Excalibur Power Plus and PC Plus models are available in bipolar or monopolar with cutting and coagulation. The Excaliburs are multi-purpose electrosurgical generators. Microprocessor control provides the user with safety and control. On the cut setting, these units provide 300 watts of output. A bipolar footswitch is available but optional as are rolling carts.
10,000V PTP in Spray COAG
It is the only ESU that allows the surgeon to adjust power settings from the surgical field with a standard ES pencil
Excalibur Plus PC Patented Controlled Output Voltage in CUT maintains minimum necessary voltage for smooth cutting through various impedance tissues with minimal thermal damage
The Excalibur Plus PC offers a scalpel like cut and three blend modes
Conmed Excallibur Plus Specifications
General
Weight: 40 lbs (18.5 kg)
Dimensions: 6.25” H x 18” W x 22.75” L (15.9 x 45.8x 57.8 cm)
Mains over current protection: Combined 2-pole circuit breaker/power switch
Power Display Accuracy: The greater of +/- 10% of display or +/- 3 watts rated load
Cooling: Natural convection, conduction, and radiation. No fan
Patient Connections to Neutral: Less than 10 µA typical
Chassis to Neutral: Less than 25 µA typical
Single Pad Monitor Mode: Two wire continuity detector, typical threshold= 10 Ohms
Dual Pad Monitor Mode: Two wire resistance monitor, typical acceptance range 10 to 150 Ohms, trip threshold typically 20% higher than the last monitor set point activation, visual indication of patient resistance
