Description
Conmed Excallibur Plus Features
The Conmed Excalibur Power Plus and PC Plus models are available in bipolar or monopolar with cutting and coagulation. The Excaliburs are multi-purpose electrosurgical generators. Microprocessor control provides the user with safety and control. On the cut setting, these units provide 300 watts of output. A bipolar footswitch is available but optional as are rolling carts.
- 10,000V PTP in Spray COAG
- It is the only ESU that allows the surgeon to adjust power settings from the surgical field with a standard ES pencil
- Excalibur Plus PC Patented Controlled Output Voltage in CUT maintains minimum necessary voltage for smooth cutting through various impedance tissues with minimal thermal damage
- The Excalibur Plus PC offers a scalpel like cut and three blend modes
Conmed Excallibur Plus Specifications
General
- Weight: 40 lbs (18.5 kg)
- Dimensions: 6.25” H x 18” W x 22.75” L (15.9 x 45.8x 57.8 cm)
- Mains over current protection: Combined 2-pole circuit breaker/power switch
- Power Display Accuracy: The greater of +/- 10% of display or +/- 3 watts rated load
- Cooling: Natural convection, conduction, and radiation. No fan
- Patient Connections to Neutral: Less than 10 µA typical
- Chassis to Neutral: Less than 25 µA typical
- Single Pad Monitor Mode: Two wire continuity detector, typical threshold= 10 Ohms
- Dual Pad Monitor Mode: Two wire resistance monitor, typical acceptance range 10 to 150 Ohms, trip threshold typically 20% higher than the last monitor set point activation, visual indication of patient resistance
